4K UHD AUTO TRACKING HDMI 2.0/12G-SDI/USB 2.0/USB 3.0 Live Streaming PTZ Camera with Tally Lights
Color
Zoom
SKU: BG-ADAMO-4K
MSRP: $2,699.00 – $2,899.00
Status: In Stock
Tech Specifications
Camera Parameters | ||
Optical Zoom | 12X | 25X |
Focal Length Range | f=3.85 mm ~ 43.06 mm ±5% | f=6.91 mm ~ 214.64 mm ±5% |
View Angle | H: 7.59°(tele) ~ 80.4°(wide) V: 4.6°(tele) ~ 50.0°(wide) |
H: 1.98°(tele) ~ 59°(wide) V: 1.12°(tele) ~ 34.14°(wide) |
AV | F1.8 ~ F3.56±5% | F1.35 ~ F4.6±5% |
Sensor | 1/2.5 inch SONY CMOS sensor | 1/1.8 inch SONY CMOS sensor |
Effective Pixels | 8.51 Megapixels 16:9 | |
Video Format | HDMI: 3840*[email protected]/50/30/25/59.94/29.97Hz; [email protected]/50/30/25/59.94/29.97Hz; [email protected]/50,30/59.94Hz; [email protected]/50/59.94Hz; 12G-SDI: 3840*[email protected]/50/30/25/59.94/29.97Hz; [email protected]/50/30/25/59.94/29.97Hz; [email protected]/50/59.94Hz; [email protected]/50/59.94Hz; USB2.0: MJPG: 3840*2160 /1920*1080 /1280*720 /1024*768 /1024*576 /800*600 /720*576 /720*480 /704*576 /640*480 /640*360 /352*288 /320*[email protected]; H264: 3840*2160 /1920*1080 /1280*720 /1024*768 /1024*576 /800*600 /720*576 /720*480 /704*576 /640*480 /640*360 /352*288 /320*[email protected]; YUY2: 800*448 /720*[email protected]; 640*360 /432*[email protected] NV12: 800*[email protected]; 640*480 /640*360 /432*[email protected] USB3.0: YUY2: 1920*1080 /1280*[email protected]/50/30/25Hz; 960*540 /800*[email protected]; 720*[email protected]; 720*[email protected]; 640*[email protected]; |
|
Minimum Illumination | 0.5Lux (F1.8, AGC ON) | |
DNR | 3D DNR | |
White Balance | Auto / Manual / One Push / Specified Color Temperature | |
Focus | Auto / Manual / One Key Focus | |
Exposure Mode | Auto, Manual / Shutter Priority / Aperture Priority / Brightness Priority | |
Aperture Parameters | F1.8 ~ F11, CLOSE | |
Shutter Speed | 1/25 ~ 1/10000 | |
BLC | Off/On | |
Dynamic range | OFF / Dynamic Level Adjustment | |
Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve | |
SNR | ≥50dB | |
Interface Features | ||
Interfaces | HDMI, 12G-SDI, LAN (support POE), USB2.0, A-IN, USB3.0, Micro SD (FAT32), RS232-IN, RS232-OUT, RS422 (Compatible with RS485), Dial switch, DC12V, Power Switch |
|
Video Compression | LAN: H.264, H.265 USB 2.0: MJPG, H264, H265, YUY2, NV12 USB 3.0: YUY2 |
|
Audio-in Interface | Double track 3.5mm linear Input | |
Audio-out Interface | HDMI, SDI, LAN | |
Audio Compression | AAC, G.711A | |
Sampling frequency | 32000, 44100, 48000 | |
LAN | 10M/100M/1000M adaptive Ethernet port, support POE and audio/video output | |
Network Protocol | RTSP, RTMP, RTMPS, ONVIF, SRT, GB/T28181; VISCA Control Protocols | |
Control Interface | RS232-IN, RS232-OUT, RS422 compatible with RS485 | |
Serial Protocol | VISCA/Pelco-D/Pelco-P; Baud Rate:115200/38400/9600/4800/2400 | |
USB Communication Protocol | UVC (video) | |
Power Interface | HEC3800 (DC12V) | |
Power Adapter | In: AC110V-AC220V; Out: DC12V/2.5A | |
Input Voltage | DC12V±10% | |
Input Current | <1.5A | |
Power Consumption | <12W | |
PTZ Parameters | ||
Pan Rotation | -170° ~ +170° | |
Tilt Rotation | -30° ~ +90° | |
Pan Control Speed | 0.1°/s ~ 100°/s | |
Tilt Control Speed | 0.1°/s ~ 70°/s | |
Preset Speed | Pan: 78.8°/s, Tilt: 31.7°/s | |
Preset Number | 255 Presets (10 presets by remote control) |
Resources
PACKAGE CONTENTS
- 1 x BG-ADAMO-4K
- 1 x IR Remote Control
- 1 x 12V/1.5A Power Supply
- 1 x RS232 Control Cable
- 1 x User Manual
Interfaces

- SDI: Connect to an SDI device up to 330ft such as a video production switcher or a video display at resolutions up to 12G ([email protected]) over SDI cabling.
- HDMI: Connect to an HDMI device such as a video production switcher or a video display up to [email protected]
- USB 3.0: Connect USB 3.0 type B cable to a PC for plug & play connectivity for any conferencing service like Skype or Zoom, supporting resolution up to [email protected]
- USB 2.0: Connect USB 2.0 type A cable to a PC for plug & play connectivity for any conferencing service like Skype or Zoom, supporting resolution up to [email protected]
- MicroSD: Record up to 1 TB of 4K video (FAT32).
- Audio In: Connect external audio sources such as a microphone or small audio mixer to embed the sound into all video output interfaces.
- RS-232, RS-422/485: Connect cascading RS-232 or RS-422/485 to control the camera(s) with a joystick controller or control software.
- LAN: Connect to a network switch via category cable to supply power (PoE), control (TCP/IP or webGUI) and stream.
- Power: Connect supplied 12V power adapter.
