Tech Specifications
BG-UPTZ-12XHSU | BG-UPTZ-20XHSU | BG-UPTZ-30XHSU | |
Lens | 12X Optical zoom | 20X Optical zoom | 30X Optical zoom |
Horizontal View Angle | 72.5°(W)~6.3°(T) | 54.7°(W)~3.3°(T) | 65.1°(W)~2.34°(T) |
Image Sensor | 1/2.8" Progressive CMOS | ||
Effective Pixels | 2.07 Megapixels (16:9) | ||
Resolution | 1080p@60/50, 1080i@60/50, 1080p@30/25, 720p@60/50 | ||
Interface | USB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN | ||
Pan Rotation | 340°(max. speed: 80°/s) | ||
Tilt Rotation | -30° to +90° (max. speed: 60°/s) | ||
Focus System | Auto/Manual | ||
S/N Ratio | ≥50db | ||
Preset Position | 9 preset positions by IR remote controller, 255 preset positions by Keyboard or PC | ||
Minimum Illumination | 0.5 Lux (F1.8, AGC ON) | ||
Exposure Control | Auto/Manual/Priority AE/Exposure Compensation/Bright | ||
Shutter Speed | 1/1~1/10,000s | ||
Gain | Auto/Manual | ||
White Balance | Auto/Manual/ATW/One-click/Indoor/Outdoor | ||
Image Effect | Full color/black and white/Electronic flip | ||
Video Output HD | HDMI, 3G-SDI, IP, USB 3.0 | ||
Control Protocol | RTSP, RTMP, ONVIF, GB/T28181 | ||
Power | 12V DC | ||
Power Consumption | Max. 30W (DC 12V) | ||
Operating Temperature | 32°F ~ 104°F / 0°C ~ +40°C | ||
Storage Temperature | -4°F ~ 140°F / -20°C ~ +60°C | ||
Camera Dimensions | (L)7 x (W)4.5 x (H)5.9in [(L)178 x (W)115.5 x (H)150.9mm] | ||
Weight | 3 lbs [1.38KG] | ||
Color | Black, Silver, White | ||
Working Environment | Indoor Only |
Resources
Documents
Software
PACKAGE CONTENTS
- 1x BZBGEAR BG-UPTZ Camera
- 1x 12V/1.5A Power supply
- 1x RS232 control cable
- 1x IR Remote Control
- 1x User Manual
Interfaces
![Interfaces image](https://bzbgear.com/wp-content/uploads/BG-UPTZ.webp)
- HDMI: Connect to an HDMI device such as a video production switcher or a video display up to 1080@60Hz.
- USB: Connect USB3.0 type B cable to a PC for plug & play connectivity for any conferencing service like Skype or Zoom, supporting resolution up to 1080@60Hz.
- SDI: Connect to an SDI device up to 330ft such as a video production switcher or a video display at resolutions up to 3G (1080@60Hz) over SDI cabling.
- Line-In: Stereo audio input for connecting mics and embedding local audio into all video output interfaces.
- System Select: Turn this dial to set desired output resolution. See manual for resolution options.
- RS-232, RS-422/485: Connect cascading RS-232 or RS-422/485 to control the camera(s) with a joystick controller or control software.
- LAN: Connect to a network switch via category cable to supply power (PoE), control (TCP/IP or webGUI) and stream.
- Power: Connect supplied 12V power adapter.
