Universal 1080P FHD PTZ HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera

Configure the Perfect Solution
Get Started

Overview

Meet the Universal 1080P FHD PTZ HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera - BG-UPTZ. This camera offers 12x, 20x, and 30x zoom options, delivering outstanding 1080p image quality through a 1/2.8" Sony CMOS sensor. With simultaneous HDMI, 3G-SDI, and USB 3.0 outputs, it seamlessly integrates into various workflows. It supports popular video protocols like ONVIF, RTSP, and RTMP, allowing compatibility with video production software and direct streaming to platforms like YouTube and Twitch. For enhanced audio/video over IP streaming, the BG-UPTZ supports NDI|HX2 with the BG-UPTZ-ND model.

Offering IR remote, IP control, and RS232/485 serial connections, it allows precise control and up to 255 camera presets. The BG-UPTZ also supports SRT for reliable internet streaming and comes in black, silver, or white. With superb auto focus and multiple output options, it's the ultimate choice for streaming and recording needs. You can choose your next ptz camera for live streaming from our extensive catalog.

What is NDI?

Network Device Interface (NDI) is a high performance AV over IP standard that allows anyone to use real time, ultra low latency video on existing IP video networks. The NDI open protocol enables professionals to share video through a local area network (LAN) with video-compatible devices. With a single ethernet cable connection, professionals can merge all stages of production from start to finish. That way, all production tasks and processes will be united, so accomplishing a creative vision will be simple. With the NDI 5.5 tool-kit, users will also be able to connect any audio device as an NDI source with NDI’s Audio Direct tool. This adds audio over IP to NDI’s revolution.

What is NDI|HX2?

NDI|HX2 is an updated version of NDI|HX1. NDI|HX2 also compresses the bandwidth, but is more efficient than NDI|HX1. With compressed bandwidth, users can have more devices on their LAN without running into latency issues. NDI|HX2 provides good quality output, low bandwidth and medium latency. The main difference compared to NDI|HX1 is that HX2 is truly a native NDI stream - all the way from the source device to the destination. This means it is a 'cleaner' implementation than HX1 and can potentially be more reliable, provide lower latency and give a more flexible connection which shares all the usual features of NDI. Learn more about NDI technology

Benefits of NDI Technology for Your Streaming Project

NDI technology presents a multitude of advantages for live streaming, encompassing high-quality video and audio, minimal latency, scalability, and seamless integration with your current hardware and software setup. It has emerged as a favored option among broadcasters and content creators seeking to provide top-notch professional live streams.

Connectivity

The BG-UPTZ's connectivity options are second to none. Its 1/2.8” Sony CMOS sensor provides crystal-clear images at resolutions of up to 1080p@60Hz, ensuring that your content looks stunning. What sets this camera apart is its versatile zoom choices. With 12X, 20X, and 30X zoom options, it adapts effortlessly to any venue's size, allowing you to capture all the details, whether you're in a small studio or a large auditorium.



Versatility doesn't stop at image quality. The BG-UPTZ is equipped with simultaneous HDMI, 3G-SDI, and USB 3.0 outputs, making it compatible with various setups and video production equipment. This flexibility means you can use it in a live production environment, connect it to a computer for streaming, or even record high-quality video directly to storage devices.



Compatibility is a top priority with the BG-UPTZ. It supports popular video protocols such as ONVIF, RTSP, and RTMP. This means that whether you're using professional video production software or looking to stream directly to popular platforms like YouTube, Twitch, or Facebook, the BG-UPTZ seamlessly integrates with your workflow. Additionally, the inclusion of a 3.5mm input jack allows for external microphones and audio systems to be effortlessly embedded into your video stream, ensuring that your audience hears your message loud and clear.

CONTROL

Precision and control are key features of the BG-UPTZ. An onboard dial enables users to lock the output resolution, preventing potential resolution discrepancies before they occur, giving you the peace of mind that your content will look consistently professional.



Control options are abundant. The BG-UPTZ can be managed via an IR remote, IP control (IP VISCA, ONVIF), or through a user-friendly browser interface. For advanced users, the RS232 and RS485 serial connections support VISCA, PELCO-D, and PELCO-P protocols, allowing for precise control and customization of your camera's settings. You can store up to 255 camera preset positions, and with the IR remote control, ten of these presets are easily accessible, making it simple to switch between your preferred angles and shots.



Moreover, this camera supports Secure Reliable Transport (SRT) technology, ensuring high-quality, low-latency video can be reliably sent over the internet. This feature is invaluable for those looking to stream with minimal delay and top-notch video quality.

Features

  • zoomfeatures
    Zoom
    Available in 12x/20x/30x optical zoom
    +10x digital
  • fluent_zoom-fit-24-filled
    Control
    IP, IR, and cascadable RS232/485 (VICSA/Pelco) + 255 preset positions
  • material-symbols_settings-input-component
    Multiple Video Outputs
    HDMI, 3G-SDI, USB 3.0, and IP-streaming working simultaneously
  • solar_play-stream-bold
    Latest Streaming Tech
    Supports H.264/H.265 video compression and RTMP(S)
  • ph_cube-focus-fill
    Superb Auto Focus
    Auto focusing algorithms resulting in quick, accurate, and stable focus
  • Power over Ethernet (PoE)
    Power over Ethernet
    Delivers power directly over an ethernet cable
  • 1/2.8" 2.07MP low-noise CMOS
  • Quiet, high-quality step motor
  • FOV between 56° & 72.5° (dependent on zoom)
  • Resolutions up to 1080p@60Hz
  • Network protocols ONVIF, RTSP, RTMP / RTMP(S)
  • 3.5mm stereo audio input
  • Shutter speed 1/1~1/10,000s
  • Available in white, silver, or black color
  • Supports NDI|HX2
BG-UPTZ-1-features

Enhanced Optical Zoom Capability

Experience exceptional clarity and precision with our versatile optical zoom lens, offering magnification options of 12X, 20X, and 30X. Whether capturing mid-range scenes or close-up details, achieve stunning shots with ease.


BG-UPTZ-2-features

Flexible Video Output

Select from a range of output options including HDMI, USB 3.0, or SDI, or harness the power of all three simultaneously to suit your streaming needs perfectly.



Seamless Audio Integration

Effortlessly embed audio into your streams using the convenient line-in port situated on the camera's rear, ensuring crisp sound accompanies your high-quality visuals.



Efficient Power and Connectivity

Utilize Power Over Ethernet (PoE) to supply both power and network connectivity via a single Ethernet cable, simplifying setup and eliminating cable clutter for a streamlined operation.

BG-UPTZ-ND-3-features

Versatile Mounting Options

Easily mount the camera onto a tripod, wall, or ceiling with the secure mounting panel located on the bottom, providing stability and flexibility for diverse filming setups.


Software background image

Download our app now and effortlessly manage multiple cameras wirelessly!

Available for Windows, macOS, iOS, and Android

Compatible with:

Videos

How to Connect and Network BZBGEAR PTZ Camera, Video Switcher and Joystick Controller
How to Connect and Network BZBGEAR PTZ Camera, Video Switcher and Joystick Controller
Command and Control Various BZBGEAR PTZ Cameras via Newly Updated BG-PTZ-Control App (Full Overview)
Command and Control Various BZBGEAR PTZ Cameras via Newly Updated BG-PTZ-Control App (Full Overview)
How to Connect BZBGEAR BG-Commander Joystick Controller to Multiple PTZ Cameras
How to Connect BZBGEAR BG-Commander Joystick Controller to Multiple PTZ Cameras
How To Network a PTZ Camera for Live Streaming Using Mac - BZBGEAR BG-UPTZ
How To Network a PTZ Camera for Live Streaming Using Mac - BZBGEAR BG-UPTZ
BZBGEAR BG-UPTZ Series Universal Live Streaming PTZ Cameras
BZBGEAR BG-UPTZ Series Universal Live Streaming PTZ Cameras
How to Facebook Live Stream with an IP PTZ Camera
How to Facebook Live Stream with an IP PTZ Camera
How to Live Stream on YouTube with an IP PTZ Camera
How to Live Stream on YouTube with an IP PTZ Camera
How to Choose the Ideal IP PTZ Camera System for Any Live Event
How to Choose the Ideal IP PTZ Camera System for Any Live Event

Mounting Ideas

Click the image below to watch a video

Tech Specifications

  BG-UPTZ-12XHSU BG-UPTZ-20XHSU BG-UPTZ-30XHSU
Lens 12X Optical zoom 20X Optical zoom 30X Optical zoom
Horizontal View Angle 72.5°(W)~6.3°(T) 54.7°(W)~3.3°(T) 65.1°(W)~2.34°(T)
Image Sensor 1/2.8" Progressive CMOS
Effective Pixels 2.07 Megapixels (16:9)
Resolution 1080p@60/50, 1080i@60/50, 1080p@30/25, 720p@60/50
Interface USB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN
Pan Rotation 340°(max. speed: 80°/s)
Tilt Rotation -30° to +90° (max. speed: 60°/s)
Focus System Auto/Manual
S/N Ratio ≥50db
Preset Position 9 preset positions by IR remote controller, 255 preset positions by Keyboard or PC
Minimum Illumination 0.5 Lux (F1.8, AGC ON)
Exposure Control Auto/Manual/Priority AE/Exposure Compensation/Bright
Shutter Speed 1/1~1/10,000s
Gain Auto/Manual
White Balance Auto/Manual/ATW/One-click/Indoor/Outdoor
Image Effect Full color/black and white/Electronic flip
Video Output HD HDMI, 3G-SDI, IP, USB 3.0
Control Protocol RTSP, RTMP, ONVIF, GB/T28181
Power 12V DC
Power Consumption Max. 30W (DC 12V)
Operating Temperature 32°F ~ 104°F / 0°C ~ +40°C
Storage Temperature -4°F ~ 140°F / -20°C ~ +60°C
Camera Dimensions (L)7 x (W)4.5 x (H)5.9in [(L)178 x (W)115.5 x (H)150.9mm]
Weight 3 lbs [1.38KG]
Color Black, Silver, White
Working Environment Indoor Only

PACKAGE CONTENTS

  • 1x BZBGEAR BG-UPTZ Camera
  • 1x 12V/1.5A Power supply
  • 1x RS232 control cable
  • 1x IR Remote Control
  • 1x User Manual

Interfaces

Interfaces image
  1. HDMI: Connect to an HDMI device such as a video production switcher or a video display up to 1080@60Hz.
  2. USB: Connect USB3.0 type B cable to a PC for plug & play connectivity for any conferencing service like Skype or Zoom, supporting resolution up to 1080@60Hz.
  3. SDI: Connect to an SDI device up to 330ft such as a video production switcher or a video display at resolutions up to 3G (1080@60Hz) over SDI cabling.
  4. Line-In: Stereo audio input for connecting mics and embedding local audio into all video output interfaces.
  5. System Select: Turn this dial to set desired output resolution. See manual for resolution options.
  6. RS-232, RS-422/485: Connect cascading RS-232 or RS-422/485 to control the camera(s) with a joystick controller or control software.
  7. LAN: Connect to a network switch via category cable to supply power (PoE), control (TCP/IP or webGUI) and stream.
  8. Power: Connect supplied 12V power adapter.
