16x16 4K UHD Seamless HDMI Matrix Switcher/Video Wall Processor/MultiViewer with Scaler/IR/Audio/IP and RS-232

NEW
Shipping Q2 2024
Configure the Perfect Solution
Get Started

Overview

The BG-4K-VP1616 supports sixteen HDMI inputs that can be independently routed to HDMI Outputs. This unit can create video walls, act as a multi-viewer and perform matrix functions! The BG-4K-VP1616 supports video wall configurations of up to 7 different modes with each monitor. It can also display sixteen pictures on the same screen and has multiple split display modes.

Connectivity and Quality

With max resolutions up to 4K@60Hz 4:4:4, the BG-4K-VP1616 is capable of producing high-quality imagery with pristine detailing and rich color. All HDMI ports on this unit are HDCP 2.2 compliant. This device also supports analog audio extraction, and audio channels can be switched independently.

Control

The BG-4K-VP1616 provides various control methods, including front panel controls, IR remote control, RS-232, and IP control. With the included IR receiver, the unit can be controlled using the provided remote even when placed out of sight, ensuring a neat installation. Additionally, users have the option to utilize the BG-SWITCH-CONTROL app, a proprietary matrix switcher control and management application available for Windows, iOS, Mac, and Android platforms. This software empowers you to effortlessly route sources, manage displays, configure image settings, adjust network settings, and more.

Alongside a comprehensive web interface, the BG-4K-VP1616 features control software that can be operated via the RS-232 connection. These interfaces enable users to fine-tune advanced features such as EDID management, mapping, and network settings.

Features

  • 16X16 Matrixing
    16x HDMI Inputs which can be independently routed to 16x HDMI Outputs
  • Video wall
    Supports multiple video walls at the same time
  • Multiview Capabilities
    Up to 16 sources can be displayed on each output in different layouts
  • HDCP Compliant
    HDCP 2.2 compliancy ensures copyright protection
  • Control Options
    Control via panel button, Remote Control, RS232 Control, TCP/IP Control
  • 4K@60Hz
    Supports resolution up to 4K@60Hz 4:4:4
  • No switching delay or picture loss during transitions
  • EDID management: Seamless scaling for the best results
  • Supports HDMI audio formats including Dolby-5.1, DTS-5.1
  • Analog audio extraction, and the audio can be independently switching

Tech Specifications

Input ports 16xHDMI
Output ports 16xHDMI
Video Format Supported 4K@60Hz, YUV4:4:4 8 bit
4K@30Hz/1080P/1080i/720P
Audio Formats Supported HDMI digital audio DTS-5.1/Dolby-5.1
HDCP Compliant HDCP 2.2 and HDCP 1.4
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Bandwidth 18 Gbit/s
Matrix mode 16x16 seamless switching
Video wall mode Multiple video wall modes
Multi-viewer mode Multiple multi-viewer modes
Operating Temperature Range 23 to +104°F / -5 to +40°C
Storage Temperature Range -14 to +140°F / -10 to +60°C
Operating Humidity Range 5 to 90 % RH (no condensation)

Resources

Documents

PACKAGE CONTENTS

  • 1x Main Unit (16x16 HDMI Matrix)
  • 1x Remote control
  • 1x Wide-Band IR Receiver cables
  • 1x CD for user manual & Command list
  • 1x 3 Pin Phoenix terminal plug
