Stereo/TOSLINK/COAX Audio Extender (Transmitter/Receiver) over Cat5e/6/7 up to 950ft
MSRP: $229.00

MSRP $229.00

3

Description

The BG-AUD-TCS is a compact audio extender designed to transmit audio signals up to 290 meters (950 feet) away. It can transmit an analog stereo signal up to 170 meters (555 feet), and TOSLINK or digital coax up to 290 meters. The transmitter has 1 x TOSLINK, 1 x COAX, and 1 x 3.5mm stereo input jacks. The receiver has 1 x TOSLINK, 1 x COAX, and 1 Stereo RCA outputs. The integrated switch lets you to manually select the desired audio input, allowing you to connect multiple sources and switch between them as needed. This is the perfect solution for any situation requiring long distance audio transmission.

Additional information

Weight 1 lbs
Dimensions 6 × 6 × 5 in

Specifications

Transmitter

Receiver

TOSLINK, COAX or AUDIO Input 1 TP IN
1 TP OUT Output TOSLINK, COAX & RCA (L+R)

General

Audio Format TOSLINK & COAX: PCM/Dolby/DTS;
AUDIO: Stereo
Sound Channel TOSLINK & COAX: 2.0-7.1
Frequency Response 20 Hz to 20 kHz, ±3 dB
Sample Rate TOSLINK & COAX: 48k/96k/192k 16bit/18bit/24bit
Transmission Distance Stereo: Up to 170m (CAT5e/6/7)
TOSLINK/COAX: Up to 290m (CAT5e/6/7)
Power Supply Input: 100VAC~240VAC, 50/60Hz; Output: 12VDC, 1A
Power Consumption 2.5W (Max)
Work Temperature -10 ~ +55℃
Humidity 10% ~ 90%
Net Weight Transmitter: 110g; Receiver: 119g
Dimension(W*H*D) 88mm x 80mm x 21.5mm

Resources

Download Manual - Click Icon Below


Download Manual

Package Contents

① 1xTransmitter
② 1xReceiver
③ 1xPower Adaptor(12VDC,1A)
④ 4xMounting Ears & 8xScrews
⑤ 8xPlastic Cushions
⑥ 1xUser Manual

Diagram

Overview

The BG-AUD-TCS is a compact audio extender designed to transmit audio signals up to 290 meters (950 feet) away. It can transmit an analog stereo signal up to 170 meters (555 feet), and TOSLINK or digital coax up to 290 meters. The transmitter has 1 x TOSLINK, 1 x COAX, and 1 x 3.5mm stereo input jacks. The receiver has 1 x TOSLINK, 1 x COAX, and 1 Stereo RCA outputs. The integrated switch lets you to manually select the desired audio input, allowing you to connect multiple sources and switch between them as needed. This is the perfect solution for any situation requiring long distance audio transmission.



Features
  • Three audio inputs can be switched: TOSLINK/COAX/Stereo
  • Three audio synchronous outputs: TOSLINK, COAX & RCA (L+R)
  • The Transmitter is powered by the Receiver 12VDC by power over Cat5e/6/7 technology
  • The transmission distance of Stereo audio signal can up to 170m over a single CATx cable, and the TOSLINK, COAX audio signal up to 290m


Specifications

Transmitter

Input: TOSLINK, COAX or AUDIO
Output: 1 TP OUT
Receiver Input: 1 TP IN
Output: TOSLINK, COAX & RCA (L+R)
General
Audio Format TOSLINK & COAX: PCM/Dolby/DTS; AUDIO: Stereo
Sound Channel TOSLINK & COAX: 2.0-7.1
Frequency Response 20 Hz to 20 kHz, ±3 dB
Sample Rate TOSLINK & COAX: 48k/96k/192k 16bit/18bit/24bit
Transmission Distance Stereo: Up to 170m (CAT5e/6/7) TOSLINK/COAX: Up to 290m (CAT5e/6/7)
Power Supply Input: 100VAC~240VAC, 50/60Hz; Output: 12VDC, 1A
Power Consumption 2.5W (Max)
Work Temperature -10°C ~ +55°C
Humidity 10% ~ 90%
Net Weight Transmitter: 110g; Receiver: 119g
Dimension(WxHxD) 88mm x 80mm x 21.5mm
MORE / LESS SPECS

Interface

Commitment to excellent service and delivering dependable products with efficiency is BZB Gear main staple and foundation.
Our main goal is to ensure your 100% complete satisfaction with our service and products!
If for any reasons you are dissatisfied with your purchase, you can return it back to BZB Gear within 60 days of purchase date for a full refund.


Resources



Package Contents
① 1xTransmitter
② 1xReceiver
③ 1xPower Adaptor(12VDC,1A)
④ 4xMounting Ears & 8xScrews
⑤ 8xPlastic Cushions
⑥ 1xUser Manual
