BG-UM-44AS
4X4 HDMI 2.0 18Gbps Matrix Switcher

4X4 HDMI 2.0 18Gbps Matrix Switcher

SKU: BG-UM-44AS
EDID (EXTENDED DISPLAY IDENTIFICATION DATA)

The EDID job is to read the information off a Display for the purpose of matching the sources which includes manufacturer name and serial number, product type, filter type, timings, size luminance, and pixel mapping. This is vital to ensure the source and display will be compatible for signal transmission and receival. When there is no picture, this may be the issue, referred to as EDID conflicts.
3RD PARTY CONTROL SYSTEM CONNECTIONS

Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
GUI/WEB UI

Easily connect to devices using a LAN connection, simply type in the default or custom IP address associated with the device. Configure and Customize settings from here for individual environments to achieve desired video settings and outcome.
18GBPS / HDMI 2.0

The maximum bandwidth possible due to the introduction of HDMI 2.0. Prior to HDMI 2.0 was HDMI 1.4 limited to 10.2 Gbps. The new technology permits resolutions of 4K@60Hz (4:4:4) while still capable of transmitting audio and control signals simultaneously.
4K 60 4:4:4 SUPPORT

Ultra HD refers to a TV resolution of 3,840 x 2,160 pixels. That's four times as many pixels than in a full HD TV, a total of about 8.3 million pixels. Having so many pixels means a higher pixel density, and you should have a clearer, better defined picture.
HDCP 2.2

HDCP stands for High-bandwidth Digital Content Protection, a copy prevention technology directed at HDMI connections. Version 2.2 is the latest, designed specifically to prevent illegal copying of 4K Ultra HD content.
AUDIO RETURN CHANNEL (ARC)

(Audio Return Channel) Connection typically in the form of SPDIF (Fiber Optic) port on a Display responsible for returning audio from the HDMI input in which a Source is connected providing sound back to a Surround Sound receiver to amplifier for audio distribution.

This high performance HDMI Matrix Switcher can switch any of these four HDMI 2.0 sources to four HDMI 2.0 displays. Each input and output supports up to 4K60 444 resolution and HDCP 2.2. The outputs can be individually scaled for 1080p. De-embedded audio as analog L/R and coaxial is available for both outputs. The ARC function can return display device audio to coaxial port output only. Advanced EDID management is supported. With its 18Gbps bandwidth and the additional features with latest HDMI standards. This switcher can be controlled from the front panel, RS-232, IR remote, or TCP/IP.

Call us for price


Features
  • HDMI 2.0, HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
  • Four 18G HDMI 2.0 video inputs support up to 4K60 444 resolution
  • Four outputs can be individually scaled for 4K→1080p
  • De-embedded audio to analog L/R and Coaxial ports output
  • ARC audio return to the coaxial ports output only
  • Built-in Web GUI for TCP/IP control
  • Advanced EDID management supported
  • Four methods of control: Front panel, RS-232, IR remote and TCP/IP
  • Compact design for easy and flexible installation
Specifications


EDID (EXTENDED DISPLAY IDENTIFICATION DATA)

The EDID job is to read the information off a Display for the purpose of matching the sources which includes manufacturer name and serial number, product type, filter type, timings, size luminance, and pixel mapping. This is vital to ensure the source and display will be compatible for signal transmission and receival. When there is no picture, this may be the issue, referred to as EDID conflicts.
3RD PARTY CONTROL SYSTEM CONNECTIONS

Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
GUI/WEB UI

Easily connect to devices using a LAN connection, simply type in the default or custom IP address associated with the device. Configure and Customize settings from here for individual environments to achieve desired video settings and outcome.
18GBPS / HDMI 2.0

The maximum bandwidth possible due to the introduction of HDMI 2.0. Prior to HDMI 2.0 was HDMI 1.4 limited to 10.2 Gbps. The new technology permits resolutions of 4K@60Hz (4:4:4) while still capable of transmitting audio and control signals simultaneously.
4K 60 4:4:4 SUPPORT

Ultra HD refers to a TV resolution of 3,840 x 2,160 pixels. That's four times as many pixels than in a full HD TV, a total of about 8.3 million pixels. Having so many pixels means a higher pixel density, and you should have a clearer, better defined picture.
HDCP 2.2

HDCP stands for High-bandwidth Digital Content Protection, a copy prevention technology directed at HDMI connections. Version 2.2 is the latest, designed specifically to prevent illegal copying of 4K Ultra HD content.
AUDIO RETURN CHANNEL (ARC)

(Audio Return Channel) Connection typically in the form of SPDIF (Fiber Optic) port on a Display responsible for returning audio from the HDMI input in which a Source is connected providing sound back to a Surround Sound receiver to amplifier for audio distribution.

HDCP Compliance HDCP 2.2 and HDCP 1.4
Video Bandwidth 18 Gbps
Video Resolution 4K2K 50/60Hz 4:4:4 4K2K 50/60Hz 4:2:0 4K2K 30Hz 4:4:4 1080p, 1080i, 720p, 720i, 480p, 480i All HDMI 3D TV formats All PC resolutions including 1920 x 1200
Output Scaling 4K to 1080p
3D Support Yes
Color Space RGB, YCbCr4:4:4,YCbCr4:2:2, YCbCr 4:2:0
Color Depth 8-bit, 10-bit, 12-bit [1080P, 4K30Hz, 4K60Hz (YCbCr 4:2:0)] 8-bit [4K60Hz (YCbCr 4:4:4)]
HDMI Audio Formats PCM2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD,  DTS, DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master  Audio, DSD
Coaxial Audio Formats PCM2.0, Dolby Digital / Plus, DTS 2.0/5.1
L/R Audio Formats PCM2.0CH
HDR Support HDR10, HDR10+. Dolby Vision, HLG
ESD Protection Human-body Model: ±8kV (Air-gap discharge),  ±4kV (Contact discharge)
Connections
Input Ports 4XHDMI Type A [19-pin female]
Output Ports 4XHDMI Type A [19-pin female] 4XL/R audio out [3.5mm Stereo Mini-jack] 4XCOAX audio out [RCA]
Control ports 1x TCP/IP [RJ45] 1x RS-232[3-pin phoenix connector] 1x IR EXT [3.5mm Stereo Mini-jack]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 220mm (W)X105mm (D)X44mm (H)
Weight 792g
Power Supply Input: AC100~240V 50/60Hz Output: DC12V/2.5A (Locking connector)
Power Consumption 10W (max), 1.56W (Standby)
Operating  Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)
Resolution /  Cable Length 4K60 - Feet / Meters   4K30 - Feet / Meters 1080P60 -  Feet / Meters
HDMI IN / OUT 10ft / 3M 30ft / 10M 42ft / 15M





Package Contents
① 1x 4x4 HDMI 2.0 18Gbps Matrix Switcher
② 1x 12V/2.5A Locking Power Adapter
③ 1x IR Remote
④ 1x 38KHz IR Receiver Cable (1.5 meters)
⑤ 2x Mounting Ears
⑥ 1x 3-pin Phoenix Connector
⑦ 1x User Manual


Warranty: 2 years
