BG-HD-MNA-4X1
Full HD HDMI 4X1 Quad MultiViewer
Full HD HDMI 4X1 Quad MultiViewer
Full HD HDMI 4X1 Quad MultiViewer
SKU: BG-HD-MNA-4X1
1080p Full HD
1080P HD OVER HDBaseT Our original powerhouse series of matrices, which come in 4x4, 6x6, 8x8 and 16x16 configurations. The PP-POH (Modular) series transmits crisp, uncompressed 1080P HD content at distances of up to 70m/230ft with no latency. With many options, this series delivers quality at a cost-ef-fective price and is the perfect choice in a still dominating 1080p world.
1080P HD OVER HDBaseT Our original powerhouse series of matrices, which come in 4x4, 6x6, 8x8 and 16x16 configurations. The PP-POH (Modular) series transmits crisp, uncompressed 1080P HD content at distances of up to 70m/230ft with no latency. With many options, this series delivers quality at a cost-ef-fective price and is the perfect choice in a still dominating 1080p world.
3RD PARTY CONTROL SYSTEM CONNECTIONS
Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
The high performance 4X1 quad multiviewer supports four routes HDMI high definition input contents be displayed on one HDMI screen and one VGA screen simultaneously. It supports analog audio output that can be selected different input source. Supports five multi-view display modes. Output resolution can be adjusted and supports the maximum up to 1920×[email protected] The product can be controlled via the front panel button and remote control.
MSRP $209.00*
*Pricing is for US only. International pricing will vary.Features
- HDMI 1.4, HDCP 1.4 compliant
- Input resolution can automate recognitionb(480i~1080P60,800x600~1920x1080)
- Output resolution can be selected by on-panel button and remote control, the maximum up to [email protected] ([email protected], [email protected])
- Audio supports LPCM 2CH
- Supports 1/2/4 windows multi-view modes
- Control is via on-panel button and remote control
Specifications
1080p Full HD
1080P HD OVER HDBaseT Our original powerhouse series of matrices, which come in 4x4, 6x6, 8x8 and 16x16 configurations. The PP-POH (Modular) series transmits crisp, uncompressed 1080P HD content at distances of up to 70m/230ft with no latency. With many options, this series delivers quality at a cost-ef-fective price and is the perfect choice in a still dominating 1080p world.
1080P HD OVER HDBaseT Our original powerhouse series of matrices, which come in 4x4, 6x6, 8x8 and 16x16 configurations. The PP-POH (Modular) series transmits crisp, uncompressed 1080P HD content at distances of up to 70m/230ft with no latency. With many options, this series delivers quality at a cost-ef-fective price and is the perfect choice in a still dominating 1080p world.
3RD PARTY CONTROL SYSTEM CONNECTIONS
Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
Utilize an array of connections for 3rd Party Control system including RS-232, LAN, IR and USB.
| Technical | |
| HDMI Compliance | HDMI 1.4 |
| HDCP Compliance | HDCP 1.4 |
| Video Bandwidth | 4.95Gbps |
| Video Resolutions | up to [email protected] |
| Color Depth | 8-bit |
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
| Analog Audio Formats | LPCM2.0 44.1KHz 48KHz |
| ESD Protection | Human-body Model： ±8kV (Air-gap discharge) , ±4kV (Contact discharge) |
| Connections | |
| Inputs ports | 4x HDMI Type A [19-pin female] 1x SEVICER [Micro USB, Update port] |
| Outputs ports | 1x HDMI Type A [19-pin female] 1x VGA [VGA-D] 1x Audio [3.5mm Stereo Mini-jack] |
| Mechanical | |
| Housing | Metal Enclosure |
| Color | Black |
| Dimensions | 185mm (W)x111.8mm (D)x21mm (H) |
| Weight | 500g |
| Power Supply | Input: AC100~240V 50/60Hz, Output: DC12V/1A (US/EU standards, CE/FCC/UL certified) |
| Power Consumption | 5.28W (max) |
| Operating Temperature | 0°C ~ 40°C / 32°F ~ 104°F |
| Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F |
| Relative Humidity | 20~90% RH (non-condensing) |
Resources
Package Contents
① 1x HDMI 4×1 Quad MultiViewer
② 1x 12V/1A DC Power Adapter
③ 1x Remote Control
④ 2x Mounting Ears
⑤ 1x User Manual
② 1x 12V/1A DC Power Adapter
③ 1x Remote Control
④ 2x Mounting Ears
⑤ 1x User Manual
Warranty: 2 years
